Contact Form : SPST , SPDT

Max. Allowable Current : 20A

Coil Type : Standard & High Sensitivity DC

Features

• High switching current 20A.

• 8mm creepage distance.

• Surge strength up to 10,000V and dielectric strength 5,000V available.

• High sensitivity DC coil type of low power consumption available.

• 1/3 horse power at 250VAC of GZ series is certified by UL.

• TV-8 at 120VAC rating of GZT model is approved by UL.

• Halogen free series available.

• Comply with RoHS and REACH regulations.

Tags: SPST(1A1B)SPDT (1C)20ADC 3VDC 5VDC 6VDC 9VDC 12VDC 24VDC 48VGZ-GZT
